DBS6000HD TRAXIS Satellite Receiver

DBS6000HD Traxis MPEG2 / MPEG4 HD Satellite Receiver

SPECIAL INTRODUCTORY PRICE

$135.00 Including Shipping in the US


Click on Picture for Full Size Photo

SPECIAL INTRODUCTORY PRICE

$135.00 Including Shipping in the US


Within the 48 Cont. United States

Click on this link to Download User Manual - Video: How to upgrade reciever via USB

FEATURES:

  • HD PVR Ready
  • Fujitsu H60 FTA + USB + PVR + MULTI CAs+ LAN(CC CAM, NEW CAMD, MG CAMD SUPPORTED)
  • Fully compliant with the DVB-S2 digital TV reception standards
  • Support DVB-S/S2 digital TV signal modulated in QPSK/8PSK
  • Input frequency range of 950MHz-2150MHz
  • Support HDTV/SDTV MPEG-2/MPEG-4/H.264 decoding Video format and 1080i,720p,576p,480p
  • USB2.0 high speed OTG controller (PVR/ Media Play/SW upgrade)
  • Ethernet 10/100 Base-T MAC interface build-in
  • HDMI/CVBS/YPbPr output
  • Support CA (CAS embedded option)
  • Dolby digital encoded bi-stream output via S/PDIF
  • DTS encoded bi-stream output via S/PDIF
  • Multi-language OSD (English, German, Arabic, Italian, Spanish, Thai..more…)
  • Multi-Scan Mode (Blind scan, default scan, TP scan)
  • Support 7days EPG, Subtitle, osd teletext
  • Audio language, intelligent graphical user interface design
  • Support DiSEqC1.0/ DiSEqC1.1/DiSEqC1.2
  • Friendly channel selection, by sort/index/find/log
  • Favorite Channel edit, parental lock
  • Variable aspect ratio(4:3,16:9)4:3 Pan&Scan Letter Box modes
  • Support USB PVR, MP3,JPG photo playback
  • Support MP3,WMA, WAV format multimedia music file
  • Support JPG, BMP, PNG format multimedia picture file
  • Photo slideshow while playing MP3
  • Support MKV, FLV, avi, dat, mpg, mpeg, ts, trp, tp, m2ts, vob, mp4, mkv, motion jpeg format
  • Manual PID/Satellite and transponder/web search
  • Transponder parameters upgraded by internet
  • Sorts: Alphabetical, satellite, free/pay, parental locks, transponder, more
  • Dimension: 230 (W) x 140 (D) x 39 (H) mm
  • Weight: 1.5 Kg (Net)
    •

    SPECIFICATIONS:

    Receiver Standard
    		 DVB-S2 Standard (ETSI EN 302 307)
    Input
    		 Input Frequency
    		 950~2150MHz
    Connector
    		 F Type
    Input Impedance
    		 75O
    Input Level
    		 -25~-65dBm
    LNB Power
    		 13/18 V
    LNB Control
    		 22KHz
    DiSEqC
    		 Ver 1.0/1.1/1.2/USALS
    Demodulation
    		 QPSK, 8PSK
    Symbol Rate
    		 2~45Mbaud (SCPC/MCPC)
    Transport Stream
    		 MPEG-2 ISO/IEC 13818-1
    MPEG Profile Level
    		 MPEG-2 MP@HL, MPEG-4 MP@L4 H.264
    Aspect Ratio
    		 4:3, 16:9
    Video Resolution
    		 1080i 50/60Hz, 720p 50/60Hz, 576p 50Hz,
    576i (PAL), 480p 60Hz, 480i (NTSC)
    Conditional Access System
    		 1 CA Card Reader Slot
    A/V Output ports
    		 RCA with CVBS, HDMI (HDCP), YPbPr with CVBS
    Left/Right analog audio output (RCA), Digital audio output (Coaxial)
    Audio Decoding
    		 MPEG1 layer I, MPEG1 layer II, MPEG1 layer III, MPEG2, AC3
    Audio Mode
    		 Stereo/MONO/Left/Right
    DVR Support
    		 DVR with USB HDD, Time shifting with USB HDD
    USB 2.0 High Speed Host
    		 1 USB 2.0 Port
    File System
    		 FAT12, FAT16, FAT32, NTFS (supports first partition)
    Media Support
    		 JPG, BMP, MP3, WMA
    Ethernet Interface
    		 10/100 Mbit
    Power Supply
    		 Input DC12V 2A
    Power Consumption
    		 28W Max / 1W Standby
    Dimension
    		 230 (W) x140 (D) x39 (H) mm
    Operating Temperature
    		 0°C to +50°C

    Click Here to Download Users Manual

    Click Here for Software Updates

    DBS6000HD Traxis MPEG2 / MPEG4 HD Satellite Receiver

    SPECIAL INTRODUCTORY PRICE

    $135.00 Including Shipping in the US


    Click on Picture for Full Size Photo

    SPECIAL INTRODUCTORY PRICE

    $135.00 Including Shipping in the US


    Within the 48 Cont. United States

    IMPORTANT
    We do not provide or condone the use of third party software. Using third party software may be illegal and will void product warranty. Do not email or call us asking about DN, DTV, etc. Our satellite receivers are designed and intended for 100% legal FTA use only. We will refuse sale to anyone whom we believe intends to use any of our products illegally or sell our products for any other type illegal use.
    Prices shown Include Shipping within the 48 Cont. United States.
